Based on the Endurant HD automated transmission, the new Endurant HD N model is optimized to integrate with Cummins natural gas engines and features new software functionality and calibrations, and a new diaphragm spring clutch from Eaton that is designed to meet the thrust bearing load requirements of natural gas engines and protect the engine for optimal performance.
The integration between the engine and transmission results in improved launch performance, improved low-speed maneuverability, and smoother shifts when compared to previous natural gas engines and automated manual transmission combinations.
The new Cummins natural gas integrated powertrain is designed for fleets looking to reduce their carbon footprint and help support their sustainability initiatives.
Eaton Cummins Automated Transmission Technologies has a broad portfolio of transmissions to help you get the job done. By answering a short series of questions about your truck and your route, we'll give you a couple of recommendations for heavy-duty automated transmissions that best fit your fleet's unique needs.
If there is a service issue, Endurant HD N uses Eaton IntelliConnect,™ a telematics-capable system that provides near real-time monitoring of vehicle fault codes, prioritizes the critical events and provides accurate and comprehensive action plans by our technical experts. Unplanned downtime is reduced and quicker repair diagnosis gets you back on the road faster.
Like all Eaton Cummins automated transmissions, Endurant is backed by the support, solutions and expertise of the Roadranger network.
Endurant HD Service Literature
You can now access digital versions of our product service literature. These digital documents are always up-to-date and contain the same real-time information you would have access to using Product Information within our ServiceRanger 4 diagnostic tool.
Click on the Troubleshooting Guide, Service Manual or Service Parts thumbnails below to access each document.
| Transmission | Linehaul and Pickup & Delivery applications: 5 years / 750,000 miles |
|---|---|
| Construction, Refuse, and Agriculture applications: 3 years / 300,000 miles | |
| Clutch | Linehaul and Pickup & Delivery applications: 3 years / 350,000 miles |
| Construction, Refuse, and Agriculture applications: 2 years / 200,000 miles |
| Transmission | 1 year; 2 year; and 2 year / 100,000 miles |
|---|---|
| Clutch | 1 year / 100,000 miles; 2 year / 150,000 miles |
| Model | Maximum Engine Torque Capacity Lb.-Ft. [Nm] |
| EHD-14112C-N | 1450 [1966] |
| EHD-16F112C-N | 1650 [2237] |
| EHD-18112C-N | 1850 [2508] |
| Overdrive (C ratio) | ||||||
|---|---|---|---|---|---|---|
| Speeds | Forward Speeds | 12 | ||||
| Reverse Gears | 1 or 2 | |||||
| Capacities | Maximum GCW lbs. [kgs] | 110,000 [49895] | ||||
| Maximum Engine Torque lb.-ft. [Nm] | 1850 [2508] | |||||
| Dimensions | Length in. [mm] | 37.9 [963.7] | ||||
| Weight lbs. [kgs] | 657 [298] | |||||
| Gear Ratios | Overall Ratio | 18.85:1 | ||||
| First Gear Ratio | 14.43 | |||||
| Forward Gears | Gear | Ratio | % Step | |||
| 1 | 14.43 | 31 | ||||
| 2 | 11.05 | 31 | ||||
| 3 | 8.44 | 31 | ||||
| 4 | 6.46 | 31 | ||||
| 5 | 4.95 | 31 | ||||
| 6 | 3.79 | 30 | ||||
| 7 | 2.91 | 31 | ||||
| 8 | 2.23 | 31 | ||||
| 9 | 1.70 | 31 | ||||
| 10 | 1.30 | 30 | ||||
| 11 | 1.00 | 31 | ||||
| 12 | 0.77 | -- | ||||
| Reverse Gears | 1 | 16.92 | ||||
| 2 | 12.95 | |||||
| Lubrication and Cooling | Lubrication Interval miles [km] | 750,000 [1,207,008] | ||||
| Oil Capacity pints [liters] | 16 [7.57] | |||||
| Recommended Oil | Eaton PS-386 | |||||
| PTO Capability | 4-bolt | No | ||||
| 6-bolt | No | |||||
| 8-bolt | Yes | |||||
| Thru-shaft | No | |||||
| PTO Speed % of Engine | 137 | |||||
| Combined PTO Torque lb.-ft. [Nm] | 385 [522] | |||||
| Typical Vehicle Types | Linehaul | Regional haul | ||||
| Beverage truck | Refuse roll-off | |||||
| Flatbed truck | Landscape truck | |||||
| Moving van | Refuse transfer vehicle | |||||
| Stake truck | ||||||
| Application approval rules and details are provided through the truck manufacturer and Eaton Cummins. | ||||||
